Downdraft Grinding Table
Suitable for grinding, polishing and other working conditions of metal and non-metal workpieces.
Performance Description
1- Integral structure, beautiful appearance, small floor area, easy to move and fix with Fuma wheel installed at the bottom.
2- Three sides surrounding design, effectively preventing the spread of dust.
3- Multi-stage high efficiency filtration, up to emission standard.
4- Drawer dust box, convenient and quick to pour dust.
5- Dustproof 5-hole socket, convenient to connect with electric tools.
6- Removable modular work surface
Standard Configuration
1- Aluminium alloy flame arrestor
2- Primary filter
3- HEPA filter
4- Dustproof 5-hole socket
5- 12L dust drawer
6- 5m power cord
Optional Components
1- Non-slip soft pad
2- IO Port (remote control)
3- Stainless steel custom machine structure
4- Working surface can be designed as round hole, square hole, long hole.
5- Working surface can be stainless steel, brass, nylon, polyurethane.
Technical Parameters
|
|
MLWF100D |
MLWF150D |
MLWF200D |
|
Motor Power |
1.1KW |
1.5KW |
1.1KW*2 |
|
Working Voltage |
220V 50Hz |
380V/50Hz |
380V/50Hz |
|
Air Volume |
1500m^3/h |
2500m^3/h |
3000m^3/h |
|
Filtering Accuracy |
0.3um |
0.3um |
0.3um |
|
Filter Material |
Aluminium alloy flame arrestor, Primary filter, HEPA filter |
||
|
Cleaning Mode |
Manual |
Manual |
Manual |
|
Noise Level |
75±3dBA |
75±3dBA |
75±3dBA |
|
Dimension |
1000*600*1000mm |
1500*800*1000mm |
2000*800*1000mm |
|
Weight |
105kg |
150kg |
260kg |
