| Model: | EAX-GP5000 |
|---|---|
| Brand: | ECOOL POWER |
| Origin: | Made In China |
| Category: | Metallurgy , Mining & Energy / New Energy / Solar Energy |
| Label: | solar power system , off solar system , solar li battery |
| Price: |
US $7500
/ Set
|
| Min. Order: | 1 Set |
| Live Chat: |  | Last Online:04 Apr, 2024 |
| Specification | DC96V-AC220V,5000W | ||||
| Solar Panel(A grade) | Maximum Power | 300W | |||
| Maximum Power Voltage | 36.2V | ||||
| Maximum Power Current | 8.28A | ||||
| Open-Circuit Voltage (V) | 42.35V | ||||
| Short-Circuit current | 8.85A | ||||
| Maximum System Voltage (V) | 1000V | ||||
| With MC4 connectors | |||||
Hybird Solar Inverter With PWM Controller |
Controller input range | DC60V-DC100V | |||
| Recommended rated voltage of input | DC72V | ||||
| Charging current | 50A | ||||
| Efficiency | 96% （Max） | ||||
| Rated Output Power | 5000W | ||||
| DC Input Voltage | 48VDC | ||||
| Rated Output Voltage | 220V±10% | ||||
| Output Frequency | 50Hz±0.5Hz | ||||
| Working Efficiency | >85% | ||||
| Output Wave | Pure Sine Wave(THD≤5%) | ||||
| Battery | Battery Type | Li-Iron-Phosphate (LiFePO4) | |||
| Rated Voltage | 48V | ||||
| Rated Capacity | 50Ah | ||||
| Nominal Capacity per stack | 9.6 KWh | ||||
| Number of stacks per system | Up to 4 stacks (9.6KWh) | ||||
| Accessories | solar panel Rack (aluminum alloy） Solar panel battery play wooden frame | ||||
| PV cable:10mm², 15meter ( one side wire with Anderson connector, the other side wire strip of 25mm) | |||||
| PV cable:4mm², 3meter （for solar panel in parallel) | |||||
| parallel plug | |||||
| Anderson connector | |||||
| User's Manual | |||||
| Quality Certificate | |||||
| Warranty Card | |||||
| Payment Terms: | TT/L/C/Paypal |
|---|---|
