| Model: | - |
|---|---|
| Brand: | TEDERiC Machinery |
| Origin: | Made In China |
| Category: | Industrial Supplies / Other Industrial Supplies |
| Label: | injection speed unit |
| Price: |
US $15000
/ pcs
|
| Min. Order: | 1 pcs |
| Live Chat: | Last Online:19 Nov, 2019 |
Introduction
DH full hydraulic series injection molding machine is of two-platen, dual cylinder injection unit and clamping force from 480 – 7000 tons. Its modularized design, free match-up of clamping and injection units can cater to customer needs, and also reduce floor area occupation and costs. The super efficiency servo IMM is being energy saving and environmentally friendly, and configured with sensitive servo driving system to give quick response. With customizable super large mold thickness and opening stroke, the machine models are especially suitable for deep-cavity plastic products of sizable mold thickness demand.
Commonly injection molding machines are toggle type, also called three platen machine, with a front, middle and back platen, but two-platen injection molding machine goes by straight clamping, with only front and back platen. The mold opening force of two platen injection molding machine is comparatively large, which makes it easy to process products of deep cavity, big material volume and complex shape, with even higher mold clamping accuracy. Besides, two platen injection molding machine can realize the independent closed-loop control of high-pressure hydraulic clamping cylinders through the development of special structure and control software. In the global market, China's ultra-large two platen injection molding machine technology currently holds the lead position.
Feature：
High precision: quick response of clamping force, repeatability precision of molding opening position within ± 0.5 mm and of injection position within ± 0.5 mm.
Stable and energy-saving: leading servo dynamic system deployed, 30ms high response and save 30%~80% energy compared to the traditional hydraulic system
Flexible: can be applied to varying types of molds.
We produce tederic machine,toggle type injection molding machine ,biggest injection moulding machine,clamping unit of injection molding machine,injection unit of injection molding machine,hydraulic clamping injection molding machine and tederic injection,we are your good choice.
