| Model: | M320R |
|---|---|
| Brand: | BLIIOT |
| Origin: | - |
| Category: | Electronics & Electricity / Electronic Components / Sense Organ |
| Label: | Digital Output modul , Relay module , Ethernet Module |
| Price: |
US $120
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:17 Oct, 2022 |
The M320R Ethernet Remote I/O Module is an industrial class, isolated designed, high reliability, high stability and high precision data acquisition module, embedded 32-Bit High Performance Microprocessor MCU, Integrated 1-2 Industrial 10/100M adaptive Ethernet module inside. It provides multi I/O, supports standard Modbus TCP, can be intergraded into SCADA, OPC server, and other automation systems. It is design for working in the harsh industrial application environment, widely used in a variety of industrial automation, security monitoring system, automatically measurement and control system.
The M320R Ethernet Remote I/O module provides a RS485 interface, through the RS485 bus, it can cascade Modbus RTU I/O devices or Modbus RTU meters, e.g.: a variety of digital input or digital outputs, analog inputs or outputs, thermal resistance IO module combination, save costs. At the same time, the Ethernet Remote I/O module has register mapping function, the cascade Modbus RTU I/O data are automatically collected to the mapping memory area, the Modbus TCP Client query without waiting then can get a quick response to meet the industrial timely requirements.
The M320R Ethernet Remote I/O module provides 8 digital outputs, supports 10Hz~300Khz high speed pulse output and 8 relay outputs. All of the I/O with high sampling frequency and special filtering strategy to ensure it’s reliable.
