| Model: | WGV450-2000 |
|---|---|
| Brand: | SINGREAT |
| Origin: | Made In China |
| Category: | Industrial Supplies / Environment Protection Facilities / Other Environment Protection Facilities |
| Label: | - |
| Price: |
US $20
/ m
|
| Min. Order: | 500 m |
| Live Chat: |  | Last Online:13 May, 2024 |
Silt curtain is well know as turbidity barrier,silt barrier or silt screen.It is a solid float device made up of solid float PVC or rubber boom with woven geotextile curtain to protect water from polluting by the silt or sediment or float in civil works near harbors or channels or shipyards.It also could be used to prevent sargassum,seaweed,control floating trash and debris and other enteromorpha from spreading into beaches,resorts,docks or ports.
|
Model/Parameter |
WGV600 |
WGV700 |
WGV750 |
WGV800 |
WGV900 |
WGV1000 |
WGV1100 |
|
Overall height(mm) |
600 |
700 |
750 |
800 |
900 |
1000 |
1100 |
|
Freeboard(mm) |
150 |
210 |
260 |
280 |
320 |
340 |
370 |
|
Draft(mm) |
380 |
390 |
400 |
420 |
490 |
540 |
560 |
|
Max, working tensile strength(mm) |
20 |
25 |
30 |
45 |
55 |
75 |
85 |
|
Length per section (m) |
20 |
||||||
|
Max, wave height to withstand(m) |
0.5 |
0.5 |
1 |
1.5 |
1.8 |
2 |
2 |
|
Max, wind speed to withstand(m/s) |
8 |
10 |
10 |
15 |
15 |
18 |
20 |
|
Max, current speed to with stand(KN) |
1 |
1 |
1.5 |
1.5 |
2 |
2.5 |
2.5 |
|
Standard connector |
ASTM connector or as customer’s requirement |
||||||
|
packing dimensions for 20m（m） |
1x1x0.6 |
1.2x1x1 |
1.2x1x1 |
1.3x1.1x1.1 |
1.4x1.5x1.2 |
1.4x1.6x1.3 |
1.4x1.7x1.4 |
