General Specification:
Size: 60X60X28mm
Rated Voltage:12V/24V
Operation Voltage:10.8~13.2V/21.6~26.4V
Rated Current:0.10~0.80A/0.06~0.50A
Speed: 2500~6500RPM/2500~6500RPM
Air flow: 3.38~9.48CFM/: 3.38~9.48CFM
Pressure: 1.98~26.73(mmH2O)/ 1.98~26.73(mmH2O)
Noise:24.8~48.0dBA/24.8~48.0dBA
Bearing System: Sleeve Bearing
Frame & Impeller:Thermal Plastic, UL 94V-0
 Lead wires:UL Type; (+):Red     (-):Black
Operation Temperature:-10℃~70℃, 35%~85%RH
Storage Temperature: -40℃~70℃, 35%~85%RH
Weight:  49.8g

Motor Protection:
Impedance Protected, Reverse Polarity Protected
