| Model: | YHZS25 |
|---|---|
| Brand: | ZLMIX |
| Origin: | Made In China |
| Category: | Industrial Supplies / Construction Machine |
| Label: | Mobile concrete batc , Mobile concrete batc , Mobile concrete mixi |
| Price: |
US $100000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:03 Sep, 2020 |
1. Short mixing time and good mixing uniformity;
2. Electronic measurement, accuracy and reliability;
3. Advanced control technologies;
4. The mixing engine adopts double shaft mandatory mixing technology, high wear resistant lining, reasonable mixing arm and blade layout, advanced lubrication design, and the mixing barrel is more durable;
5. Modular design, easy maintenance, installation, transfer and cost savings;
6. Multiple material delivery technologies and equipment;
Main technical parameter of YHZS mobile concrete mixing plant
|
Model |
YHZS25 |
YHZS40 |
YHZS50 |
YHZS75 |
|
|
Capacity |
25 m³/h |
40 m³/h |
50 m³/h |
75 m³/h |
|
|
Mixer |
Type |
JS500 |
JS750 |
JS1000 |
JS1500 |
|
Power |
18.5kw |
30 kw |
37 kw |
2*30 kw |
|
|
Discharging capacity |
0.5 m³ |
0.75 m³ |
1 m³ |
1.5 m³ |
|
|
Aggregate bin |
PLD1200 |
PLD1200 |
PLD1600 |
PLD2400 |
|
|
Weighing accuracy |
Aggregate |
±2% |
±2% |
±2% |
±2% |
|
Cement |
±1% |
±1% |
±1% |
±1% |
|
|
Total power |
56.5kw |
76 kw |
88 kw |
112 kw |
|
|
Gross weight |
15t |
17.5t |
19t |
21t |
|
|
Max. trailing Speed |
40 km/h |
40 km/h |
40 km/h |
40 km/h |
|
|
Voltage |
AC380V/50Hz |
AC380V/50Hz |
AC380V/50Hz |
AC380V/50Hz |
|
| Payment Terms: | TT/LC |
|---|---|
