SPECIFICATION

Planer

Thicknesser

Working tables

300*1500mm

Working table

300*660mm

Cutterblock diameter

70mm

Feed speed

7m/min

Cutterblock rotation speed

5700r.p.m

Max. working height

220mm

N. of knives

3

Min. working height

4mm

knives dimensions

300*20*3mm

Cutterblock rotation speed

5700r.p.m

Max table adjustement

4mm

Max. cutting depth

4

Mortiser

Circular saw

Working table

250*500mm

Working table

220*1000mm

Longitudinal stroke

205mm

Main Saw Speed(r.p.m)

4500r.p.m.

Trasversal stroke

95mm

Main Saw Diameter

250mm

Vertical stroke

90mm

Main Spindle Diameter

30mm

Churck

16mm

Max. Cutting Height

80mm

Churck rotation speed

5700r.p.m.

Max cutting width

500mm

Shaper

Tilting saw blade

45°

Working tables

220*1000mm

Max cutting height 45°

50mm

Shaft rotation speeds

2000/3100/4400/7000r.p.m

Scoring Saw Speed(r.p.m)

7000

Standard shaft diameter

30mm

Scoring Saw Diameter

90

Spindle lenght

105mm

Scoring Spindle Diameter

22

Shaft vertical stroke

115mm

Tenoning carriage

Max. tool diameter

160mm

Carriage dimensions

1250x315mm

Max. tenoning depth

55mm

Carriage stroke

1250/1600mm

Standard accessories

Optional accessories

N°2 clamp lever

●

Single-phase motor

3,0 HP- 2,2KW

Sharper fence

●

Increasing 3-phase motor

4,0 HP- 3,0KW

Service wrenches

●

Contouring fence

●

Mortiser chuck

●

Wescott(Chuck)

16mm

Table extensions with swinging arms

860x600mm

Carriage stroke

1600/1600mm

Guards on mortiseur chuck

●

Carriage stroke

1800/1800mm

3 pcs. planing knives

●

Carriage stroke

2200/2200mm

Planer guide

●

Tenoning with protection shelf

●

Saw guide

●

Bridge sefety hood on planer

●

3-phase motor power

3,0HP - 2,2KW

Weight

550KG
