| Model: | TCZP |
|---|---|
| Brand: | TECHANG |
| Origin: | Made In China |
| Category: | Industrial Supplies / Mining Machine |
| Label: | Vibrating table , Vibrating separator |
| Price: |
US $600
/ Set
|
| Min. Order: | 1 Set |
| Live Chat: | Last Online:17 Jan, 2018 |
1. Brief introduction:
Vibrating Tables are designed to settle and compact dry bulk materials in various types of containers. Their application provides either a sizeable increase in the net weight of the container or reducing in the container size with subsequent savings in shipping and storage space.
Vibrating Tables are available in two types Electromagnetic & Electromechanical. The choice of the proper type and model depends upon the application, characteristics of the material or objects being handled, its reaction to vibration, the maximum weight to be handled and the type of container.
2. Application:
ZDP series Vibrator force concret vibrating table can be widly used in metallury,mould,food,Chemical and Building material etc
3. Features:
4. Specification:
We have vary models of Factory Price Cement Manufactures Platform Vibration according to different requirements of customers.
|
Model |
Area(m*m) |
Power(kw) |
Amplitude(mm) |
Weight(kg) |
|
ZDP-500*500 |
0.25 |
2*0.25 |
2-5 |
300 |
|
ZDP-1000*1000 |
1 |
2*0.4 |
2-5 |
600 |
|
ZDP-1200*1200 |
1.44 |
2*3.0 |
2-5 |
1200 |
|
ZDP-1500*1500 |
2.25 |
2*3.0 |
2-5 |
2000 |
|
ZDP-3000*3000 |
9 |
6*1.5 |
2-5 |
3000 |
5. FAQ:
Q: What information do I need to provide for getting an accurate quotation about the products?
A: 1.Material’s name, bulk density, and water content
2. Capacity you required___kg/h
3. What’s the purpose for our machine? Filtering impurities or Classification?
4. The mesh size for each layer
5. Voltage and frequency
Q:How long for the delivery time?
A: 5-10 working days for conventional product.
Q: How long for warranty time?
A: 12 months from the shipping date.
Q:Can your engineer come to the construction site to guide the installation?
A: yes, we can arrange our engineer to guide your installation, and salary is 150USD per day for one person, the air ticket/ visa/ local accommodation/ local traffic is in charge of customer.
Generally there is no need to send our engineer to guide, because we will provide detailed installation drawings to the customer, the customer only need to find special installation team to execute.
