Bitumen Roof Sheet corrugated roofing material

Model:-
Brand:KRS
Origin:-
Category:Construction & Decoration / Brick & Tile / Bricks Tiles
Label:itumen Roof Sheet , asphalt roof shingle , asphalt roof tile
Price: US $1 / pc
Min. Order:100 pc
Inquire Now Add to Basket

Member Information

Detail

Qingdao KRS Perfect Roof Co.,Ltd.

Free MemberShan Dong - China
Live Chat:Last Online:09 Jun, 2021

Product Description

itumen Roof Sheet, corrugated roofing material

Bitumen Sheet

Uses:

Widely used for roofing purposes

Available in various sizes as per clients' requirements

Features:

High strength

Durable finish standard

Easy to install



Corrugated Bitumen Roofing Sheets - Green

Sheet size 950mm (wide) X 2000mm (long)

Corrugated Bitumen Sheets are ideal for use in agricultural buildings, sheds animal housing and industrial roofing applications.  The sheets provide an excellent dimensional stability and in time develop a full intense colouring through the natural oxidation of the bitumen.  The sheets are extremely light and flexible whilst still incredibly strong.  They are resistant to external agents and acids and are 100% asbestos free.

Sheets are supplied with a 20 year warranty covering the waterproofing of the product.



Laying Instructions

Preparation of the roof prior to laying:

Any pitch below 10 degrees should be boarded with an appropriate plywood or similar.

For pitches above 10 degrees the following batten spacings should be used.

For a loading of 200kg/m² battens should be spaced at 460mm centres.

For a loading of 350kg/m² battens should be spaced at 310mm centres.

It is recommended to impregnate all of the timber that makes up the the supporting frame of the roof.

Lapping of the panels:

Side lap - one corrugation

Head lap - minimum of 150mm

Fixing the sheets:

Sheets should be secured using our zinc plated bitumen fixing nails.  Two rows of nails should be driven in parallel to the direction of the head and at each side of the sheet.  Nails should be driven in to the crown (the uppermost part) of the sheet.  Subsequent rows of nails should be used every third corrugation.

Sheets should be layer as per the diagram below.


Product Image

Bitumen Roof Sheet corrugated roofing material 1
Img 1
Bitumen Roof Sheet corrugated roofing material 2
Img 2
Bitumen Roof Sheet corrugated roofing material 3
Img 3
