| Model: | 0308 |
|---|---|
| Brand: | HCN |
| Origin: | Made In China |
| Category: | Industrial Supplies / Construction Machine |
| Label: | digger products , digger attachments , skid steer digger |
| Price: |
US $1500
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:03 Nov, 2016 |
Description:
Skid steer digger can be installed skid steer loaders and other machines.
HCN brand digger attachments are suitable for general clay, soil mining and other lighter working environment.
Features:
1.The seat of skid steer digger can adjust.
2.Spacious cab with safety glass.
3.Electric drive unit.
Application Field:
HCN digger attachment is widely used for pipelines from the gas, water, electricity, telecommunications, etc and landscaping.
Technical Specifications:
|
Model |
030804 |
030806 |
030808 |
Mini030801 |
|
Total Length A(mm) |
1810 |
1810 |
1810 |
1810 |
|
Total Width B(mm) |
1200 |
1200 |
1200 |
630 |
|
Total Height C(mm) |
600 |
600 |
600 |
600 |
|
Working Width D(mm) |
354 |
500 |
645 |
354 |
|
Digging Depth(mm) |
1500 |
1500 |
1500 |
1500 |
|
Bucket Rotation Angle(°) |
135 |
135 |
135 |
135 |
|
Weight |
174 |
181 |
190 |
82 |
|
Capacity（m3） |
0.04 |
0.06 |
0.08 |
0.04 |
AS: HCN products are constantly updated and improved, We keep the right to change parameters and design without informing user in advance. Product appearance and color in the photo may be different from actual products, please kind prevail.
Our Services:
Xuzhou HCN Attachments Manufacture Co.,Ltd. (hereinafter referred as HCN attachments) warrants that its products sold are free from defects in material and workmanship and meets HCN's current standards. The warranty period of key parts (Hydraulic Motor, Engine, Hydraulic Cylinder, Hydraulic Pump ) is 6 months or 500 working hours counting when the machine arrive to objective port. Whichever occurs first, according to the first in the calculation.
