| Model: | ZKBM |
|---|---|
| Brand: | Zhengke |
| Origin: | Made In China |
| Category: | Industrial Supplies / Mining Machine |
| Label: | briquetting press , briquetting machine , briquetting press |
| Price: |
US $3000
/ set
|
| Min. Order: | 1 set |
| Live Chat: | Last Online:19 Dec, 2017 |
ZKBM430 anthracite coal briquetting press machine anthracite briquette making machine
Product Description
Product Introduction
| Product name | Briquette press, briquetting press, briquetting machine, briquette machine |
| Model | ZKBM430 |
| Capacity | 6-8t/h |
| Dimensions |
L1800mm*W2100mm*H2250mm |
|
Package |
Export standard |
|
Rollers material |
65-Mn/9Crr2Mo |
|
Features |
High pressure. |
|
Compact structure. |
|
|
Easy to install and operate. |
|
|
Long working Life. |
|
|
Certification |
ISO9001:2008 & CE certificate. |
|
Loading Port |
Qingdao |
|
Payment terms |
T/T with 30% deposit and 70% balance before delivery. |
|
MOQ |
1 set |
|
Standard briquettes size |
50mm diameter. |
|
Briquetting method |
Wet briquetting through rollers |
|
Note |
|
|
We will offer you price referring to your detail request, so please kindly inform us of the material, size, moisture content, capacity per hour, briquettes' size & shape which you prefer. And the special offer will be given. |
|
Working Principle
| Anthracite Briquetting Machine |
|
1)This series of briquette making machine will pass the powder on to the two pressure roller through the reducer.
2)The two sides and roll rotation, in both the rotating roll, natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger.
3)When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials becomes a finished product from the powder ball. |
Shape of Final Briquettes
These briquettes can be designed of round ball shape, oval shape, oblateness shape, elongated shape, square shape etc. This machine is widely used in coal industry and metallurgy in dustry.
Technical Parameter
| Model |
Roller Diameter (MM) |
Capacity (T/h) |
Power (KW) |
Briquettes shape and size |
| ZKBM290 | 290 | 1-3 | 5.5 | Defined by users |
| ZKBM360 | 360 | 4-6 | 11/15 | |
| ZKBM430 | 430 | 6-8 | 18.5 | |
| ZKBM500 | 500 | 8-12 | 18.5/37/45 | |
| ZKBM500-3 | 500 | 6-8 | 37 | |
| ZKBM500-4 | 500 | 8-12 | 45 | |
| ZKBM650 | 650 | 10-15 | 37/55 | |
| ZKBM750 | 750 | 15-20 | 75/90/110 | |
| ZKBM850 | 850 |
20-25 |
90/110 | |
| ZKBM1000 | 1000 |
25-30 |
90/110/132 |
