Features

Maximum equivalent-time sampling rate (repetitive signal) - 20MSa/s

Maximum real-time sampling rate - 2MSa/s

Resolution - 8 bits

Record length - 256 bytes

Analog bandwidth - 1MHz

Vertical sensitivity - 100mV/Div - 5V/Div

Vertical position adjustable with indicator

Input impedance - 1M ohm

Max input voltage - 50Vpk (1x probe) [500Vpk for 10x probe]

DC/AC/GND coupling

Horizontal - 0.5us/Div - 10m(minute)/Div

Auto/Normal/Single trig modes

Rising/Falling edge trigger

External trig available

Trigger output is available, which makes it possible to cascade scopes to do multi-channel capture.

Trigger level adjustable with indicator

Hold/run feature

Save/recall up to 6 captures

FFT function available - size of 256 points and 512 points selectable, sampling rate of 1Ksps to 2Msps selectable

Transfer screen to PC as bitmap file via serial connection

Built-in 500Hz/5Vpp test signal

Frequency Meter (For TTL level input signal)

Auto switching between Oscilloscope Mode and Frequency Meter Mode

9V DC power supply

Dimension: 110mm X 65mm X 25mm (without case)

Weight: 125 gram (not including probe and power adapter)
