| Model: | NF-911 |
|---|---|
| Brand: | NOYAFA |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Electronic Measurment Apparatus |
| Label: | power meter , fiber tester , optical meter |
| Price: |
US $82
/ pc
|
| Min. Order: | 30 pc |
| Live Chat: |  | Last Online:05 Aug, 2020 |
Item Specifics:
Is_customized : Yes
Brand Name : Noyafa
Model Number : NF-911
Place of Origin : Shenzhen.China
Interface: FC ( ST/SC interchangeable)
Wavelength: 800-1700nm
Output: 5mW/ 10mW/ 20mW/ 30mW
Power : 1.5V x 3pcs
Warranty : 1 Year
Main functions:
1. Measurement of the power of optical sender (dBm and W).
2. Insertion loss test of optical devices.
3. Light source function
4. Check fiber breakage, winding,ect.
5. New REF user-defined.
6. FC/SC/ST general-purpose interface.
7.Wavelength:850/1300/1310/1490/1550/1625nm(powermeter)
8 .wavelength:1310 / 1550nm( light source)
9. wavelegnth: 650nm (VFL)
Technical indexes:
| Model | NF-911 | ||
| Power meter | Power detecting range(dBm) | -70 ~ +10 | -50 ~ +26 |
| Wavelenth (nm) | 800-1700 | ||
| Probe | InGaAs | ||
| Detection limit | ∮1.0mm | ||
| Standard wavelenth | 850, 1300, 1310, 1490, 1550, 1625nm | ||
| Display resolution | 0.01dBm | ||
| Light source | Modulation frequencies | CW/270Hz,1KHz,2KHz | |
| Standard wavelenth | 1310, 1550nm | ||
| Emitter type | FP-LD | ||
| VFL | Emmiting Energy | 5mw/ 10mw/ 20mw/ 30mw selectable | |
| Standard wavelenth | 650±10nm | ||
| Working temp | -20 ~ +70℃ | ||
| Power supply | 1.5V*3pcs | ||
| Overall dimension | 160x75x32mm
|
||
| Payment Terms: | TT/paypal |
|---|---|
