Solar Water Heater Factory China solar collector factory solar system DR15

Model:DR15
Brand:Ruierfa
Origin:Made In China
Category:Consumer Electronics & Lighting / Water Heater
Label:Solar water heater , Solar heater , Heater factory
Price: US $90 / SET
Min. Order:50 SET
Inquire Now Add to Basket

Member Information

Detail

Tangshan Dingre Solar Energy Science Co.,Ltd

Free MemberHe Bei - China
Live Chat:Last Online:29 May, 2016

Product Description

Material of DR Solar Water Heater

1. Vacuum tube:

1.1.Three target solar vacuum tube, borosilicate glass



2. Water tank:

2.1.Inner tank: SUS304-2B food class stainless steel, thickness 0.5mm

2.2.Outer tank: Materials are optional

2.2.1.Color steel, thickness 0.41mm

2.2.2.SUS201 stainless steel, thickness 0.41mm

2.3.Insulation: Integrated high density polyurethane foam, thickness 60mm, density 40kg/m 3



3. Bracket:

3.1.Materials are optional

3.1.1.Galvanized steel, thickness 1.5mm

3.1.2.Aluminum alloy steel, thickness 1.2mm

3.2.Bracket angle: According to customers ' requirements



4. Assistant tank(for automatic water loading):

4.1.Inner tank: SUS304-2B food class stainless steel, thickness 0.5mm

4.2.Capacity of the tank are optional

4.2.1.3L

4.2.2.5L



Other Information of DR Solar Water Heater

1. Max working pressure: 0.06 Mpa

2. Heating preservation hours: 48-72 hours



Characteristics of DR Solar Water Heater

This type solar water heater uses high temperature borosilicate glass vacuum tubes as a heat absorbing element. This system uses the thermosiphon principle. The vacuum tubes are pl ed into the bottom of the water tank. The water is filled inside the vacuum tubes, the vacuum tubes transform solar energy to thermal energy. The temperature of the water inside the vacuum tubes will rise to a high temperature. With the thermosiphon principle, the hot water in the vacuum tubes rises and arrives in the water tank. The cold water inside the water tank returns to the vacuum tubes. As long as the sun shines this repeated process of continuous circulation the water is heated up till it reaches a high temperature.



The solar system of this type solar water heater has excellent high absorption properties and low emittance rate. The output of a solar water heater will depend on the amount of solar energy that is available. On a good sunny day with 6 to 7 hours of sunlight, the solar vacuum tubes will collect enough solar energy to heat water up to 65°C/149°F, and the highest temperature of water can reach up to 95°C/203°F, in such a way that you can see steam coming from the vent.



The solar water heater performs very well during rainy days and overcast conditions with low temperatures. With the solar vacuum tube technology, the reliability of the system increases, since the temperature inside the vacuum tubes is independent of the surrounding temperature.



We are a solar water heater factory with over 10 years expirences in China. We supply OEM for 2 famous brands Solar Water Heater companies. If you are looking for Solar Water Heate supplier in China, we can be your best choice.



Specification of DR Solar Water Heater

Vacuum tube

Qty of tubes pcs

Effective area(㎡)

Capacity of tank (L)

Application on people number

Φ5 8x1800mm

10 1.376 100 2-3
12 1.674 120 3
15 2.064 150 3-4
18 2.478 180 3-5
20 2.755 200 3-6
24 3.310 240 7-8
30 4.142 300 8-10




Product Image

Solar Water Heater Factory China solar collector factory solar system DR15 1
