| Model: | CEX-8101 |
|---|---|
| Brand: | Chengerxun |
| Origin: | Made In China |
| Category: | Chemicals / Adhesives & Sealants |
| Label: | Epoxy Resin Adhesive , Epoxy Adhesive , Epoxy Glue |
| Price: |
US $58
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:14 Apr, 2016 |
Single Epoxy Resin Adhesive for Encapsulation
Ultra-strong adhesion to various surface High thermally conductive acrylic adhesive Double-sided pressure-sensitive adhesive tape Effectively replace lubricating grease and mechanical fastening |
CEX-8101 high hardness glue is one kind of high temperature curing type of liquid epoxy materials, with high temperature curing. It for the vast majority of material all have good adhesive ability, can be used for relay, glass, metal, plastic bonded materials.
CEX-8101 One component of epoxy adhesive has the following characteristics:
1. In 120 °C under the conditions of the 60 minutes fast curing
2. This product is liquid, don't need to mix, easy to use
3. Have stable mechanical and electrical properties between -45°C-150°C
Warnings for one component epoxy glue :
Handling: Avoid contact with eyes, skin and clothing. Avoid breathing vapor and mist.
Wash thoroughly after handling
Storage: Keep in a cool, well ventilated area away from heat, sparks and open flame. Keep container tightly closed until ready for use.
Technical Data:
| Model No. | Appearance | Color | Viscosity25ºC | Gravity25ºC | Condition of cure |
| CEX-8101 | Paste | Black,White,Grey... | 3.5-4.5×104 cps | 1.52g/3 | 120ºC/60min or80ºC/120min |
| Characteristics after curing | ||||||||||
| Model No. | Hardness(Shore D) | Distortion temperatureºC | Tensile strength(kg/mm2) | Coefficient of linear expansioncm/cm/ºC | Coefficient of heat release | Water absorption %24h | Delectric constant(1KH)Z | Volume resistance 25ºC | Surface resistance25ºC | Withstand voltage 25ºCKv/mm |
| cm2/ºC/cm | Ohm-cm | Ohm | ||||||||
| CEX-8101 | 85 | 160 | 220 | 53 ×10-6 | 4×10-3 | 0.05 | 3.8~4.2 | 2.35 × 1015 | 2.2× 1014 | 20~23
|
| Payment Terms: | TT |
|---|---|
