SPECIFICATIONS:
Suitable materials:dustless paper,nonwoven fabrics...
Raw Material:25g/m2-80g/m2
Fold Width:86-115mm(adjustable)
Cutting Length:100-300mm(digital adjustable)
Splitting Width:150-305mm(per sheet)
Capacity:2000-4000 sheets/min or 25-80 bags/min
Splitting device:Double line 12 channel (Jumbo Roll width 600-1450mm)
Counter:Automatic/set pile.
Fold Type:Continue type or V,Z,C fold type.
Moisture:100%-400%(adjustable)
Water storage:2 sets of 600 Ls stainless mixer tank.
Power:Ac 380V.,50/60Hz.,15KW
Machine Size:14000(L)3500(W)2200(H)mm
Machine Weight:NM.9000KGS
Flowing Chart: Raw Material-Splitting-Folding-Moisture-Cutting-Pile-Transport-Filling-Film Hole making-Sticker set-Wrapping-Finishing
| Payment Details: | LC/TT |
| Standard Met: | ISO9001&CE |
