| Model: | KG50/KG50S |
|---|---|
| Brand: | XIANFENG |
| Origin: | Made In China |
| Category: | Construction & Decoration / Door / Automatic Door |
| Label: | industrial door , rolling door , sectional door |
| Price: |
¥1
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:12 May, 2016 |
BASIC INFO
KG50/KG50S-1/KG75S-1
Main Function
● The unique built-in braking system can furthest reduce the inertial stroke of industrial doors and make stop positions of doors accurate;
● The safe and reliable disengaging wrench facilitates the installation of users, the adjustment and maintenance of balancing springs and use during power outage;
● Having a thermal protection function, and high safety and reliability;
● Above IP54 of safety protection class;
● The low-temperature lubricating oil ensures that the machine runs stably, has low noise and a long service life, and is suitable for working in cold areas;
● Mechanical and electrical integration; the devices such as a remote control, a safety air bag and a photoelectric switch are optional;
● Convenient and accurate stroke adjustment;
● The performance parameters of the product are completely in accordance with the industrial standard of Industrial Sliding Door Openers of MOHURD.
Technical parameters
|
Type |
KG50 |
KG50S-1 |
KG75S-1 |
|
Input Voltage |
220×(1±10%)V 50Hz |
380×(1±10%)V 50Hz |
380×(1±10%)V 50Hz |
|
Motor Speed |
1400rpm |
1400rpm |
1400rpm |
|
Output Rotational Speed |
32rpm |
32rpm |
24rpm |
|
Output Torque |
30N.m |
50N.m |
75N.m |
|
Motor Power |
300W |
400W |
400W |
|
Limit the maximum number of laps |
The output shaft may turn 28 laps |
The output shaft may turn 28 laps |
The output shaft may turn 28 laps |
|
Aperture of Output Shaft |
Ø25.4mm |
Ø25.4mm |
Ø25.4mm |
|
Keyway Size |
6mm |
6mm |
6mm |
|
Thermal Protection Temperature |
120℃ |
120℃ |
120℃ |
|
Working System |
S2:20% S3:10min |
S2:25% S3:15min |
S2:25% S3:15min |
|
Operating Ambient Temperature |
-20℃～+45℃ |
-20℃～+45℃ |
-20℃～+45℃ |
|
Overall Dimension |
100﹡233﹡360 |
100﹡233﹡360 |
100﹡233﹡360 |
|
Main Machine Mass |
12kg |
12kg |
12kg |
|
Recommend the use of range |
16m² |
25m² |
32m² |
KG50/KG50S-1/KG75S-1(Z）
It can be installed in standard lifting places or places with limited space in height direction.
KG50/KG50S-1/KG75S-1(F）
It is suitable for places with central beams and adequate space in height direction.
| Payment Terms: | T/T |
|---|---|
