| Model: | - |
|---|---|
| Brand: | - |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Other Electrical & Electronic |
| Label: | LED P4 screen , LED screen P4 , LED P4 indoor |
| Price: |
US $1
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:07 Jun, 2017 |
|
Main Technical Parameters for Indoor Series |
|
|
Model |
SGI-P4 |
|
Pixel Pitch(mm) |
4 |
|
Physical Density(dot/m²) |
62,500 |
|
LED Configuration |
1R1G1B |
|
LED Type |
SMD2121 |
|
Model Size(mm*mm) |
128x128 |
|
Module Resolution( W*H) |
32 x 32 |
|
Drive Mode |
1/16 scan |
|
Brightness(cd/m²) |
≥1600 |
|
Max Power Consumption(W/ m²) |
590 |
|
Average Power Consumption( W/m²) |
200 |
|
Cabinet Size(mm*mm) |
640*640 |
|
Cabinet Resolution(W*H) |
160x160 |
|
Mini. View Distance (m) |
3 |
|
View Angle(deg.) |
Horizontal≥120℃,Vertical≥120℃ |
|
Grey Scale |
≥16 bits |
|
Refresh Rate( Hz) |
≥960 |
|
MTBF |
>10,000 hours |
|
Life Span |
≥100,000 hours |
|
Working Input Voltage |
AC220V/50Hz or AC110V/60Hz |
|
Module Display Brightness Uniformity |
<2% |
|
Earth Leakage Current |
<3mA |
|
Temperature-operating |
-25℃~45℃ |
|
Humidity-operating |
10%~95% |
|
Operating System |
Windows98/me/2000/NT/XP/W8/Vista/W7 |
| Payment Terms: | TT |
|---|---|
