| Model: | CT-4008-5V6A-S1 |
|---|---|
| Brand: | NEWARE |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Electricity Meter & Instrument |
| Label: | Monitoring instrumen , Battery charge , Battery cycler |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:04 Nov, 2019 |
|
Description |
Product Specification |
||||
|
AC Input |
AC 110V±10% 50Hz |
||||
|
Power |
448000 |
mW |
|||
|
Resolution |
AD: 16bit; DA: 12bit |
||||
|
Input Impedance |
≥1MΩ |
||||
|
Voltage |
Measuring Range |
Charge: 10mV~5V |
Discharge: 10mV~5V |
||
|
Discharge Min Voltage |
1.2V |
||||
|
Accuracy |
± 0.1% of FS |
||||
|
Stability |
± 0.1% of FS |
||||
|
Current |
Range |
Rang1:0.0001A-0.1A Rang 2: 0.1A-6A |
|||
|
Accuracy |
± 0.1% of FS |
||||
|
Stability |
± 0.1% of FS |
||||
|
Power |
Output Power Per Channel |
30000mW |
|||
|
Stability |
± 0.2% of FS |
||||
|
Time |
Rise Time |
20ms (0~Full Range) |
|||
|
Step Time |
≤ (365*24) hour/step |
Time Format 00：00：00 (h:min:s) |
|||
|
Data Acquisition |
Intervals |
Time interval Δt:（1s~60000s） |
|||
|
Voltage interval ΔU: （10mV~5V） |
|||||
|
Current interval ΔI: （12mA~6000mA) |
|||||
|
Frequency |
10Hz |
||||
|
Charge |
Modeof Operation |
CCC, CVC, CC & CVC,CPC,CC&CCC |
|||
|
End Conditions |
Voltage, Current, Test Time, Capacity |
||||
|
Discharge |
Modeof Operation |
CCD, CPD |
|||
|
End Conditions |
Voltage, Current, Test Time, Capacity |
||||
|
Pulse |
charge |
CCC 、Constant power mode |
|||
|
|
Discharge |
CCD、Constant power mode |
|||
|
|
Min Pulse Width |
500ms |
|||
|
Automated Switch |
Automated swith from charge to discharge for each pulse |
||||
|
End Condition |
Voltage, Test Time |
||||
|
DCIR testing |
Support DCIR testing |
||||
|
Cycle |
Loop Measure Range |
1~65535 times |
|||
| Payment Terms: | TT |
|---|---|
