C purlin roll forming machine

Model:100-300
Brand:Believe Industry
Origin:Made In China
Category:Industrial Supplies / Construction Machine
Label:roll forming machine , c purlin roll form , z purlin machine
Price: US $25000 / set
Min. Order:1 set
Inquire Now Add to Basket

Member Information

Detail

Shanghai Believe Industry Co., Ltd

Free MemberShang Hai - China
Live Chat:
点击这里给我发消息Last Online:23 Nov, 2017

Product Description

Description:
This C purlin forming machine is used to manufacture series of C-shaped steel purlin. The machine is mainly composed of uncoiler, flattening device, forming machine, cutting equipment, collection table, hydraulic station, and control system, etc. Controlled by PLC, this machine is easy to operate. This equipment utilizes combined mould design, and so a C purlin forming machine can manufacture products of many different specifications. In that way, it saves production cost as well as improves our product competitiveness.

Properties:
The frame of C purlin forming machine adopts formed steel construction and after welded, this machine utilizes integrity processing technology. It enjoys rational and beautiful structure, strong carrying ability, and stable and reliable performance. The forming roller of this machine is designed by professional technicists.
The machine undergoes high precision processing and heat treatment before chromeplate. So this machine is characterized by high forming precision and long service life.

The main components of this device are from products of famous brands, thus ensuring the whole performance and quality. Controlled by PLC, this machine is easy to operate, thus workers without special training can operate it very well. This equipment is convenient to debug, and enjoys low noise and high efficiency.

Operation and Points That Need Attention:
The C purlin forming machine is totally controlled by PLC. So only by inputting related production data such as number of products, length and punching dimension, users can start this machine to do manufacturing. If users want to adjust this machine or something else, they have to stop the machine first and carry out relevant operation.

Maintenance and Lubrication:
Users should regularly do lubrication for chains, wheels, bearings and speed reducer, etc. And the forming rollers and machine should be kept clean.

Transportation and Packaging:
This kind of machine should adopt nude packaging and sea shipping by container.

Parameters:
Suitable material: cold rolling steel, hot rolled coils, galvanized coils and general carbon steel, etc.
Suitable thickness: 0.45-15mm, 1.5-3mm (depending on specific requirements of users)
Forming specifications: depending on specific requirements of customers
Forming speed: 10-15m/min
Main motor power: 5.5-18.5Kw (depending on specific requirements of users)
Hydraulic punching: hydraulic cutting without wastes
Hydraulic station power: 3-7.5Kw (depending on specific requirements of users)
Control system: PLC systems from Mitsubishi and Panasonic products, electrical appliances of famous brands
Optional accessories: hydraulic uncoiler


Payment Terms:TT 30% as deposit, 70% before shipment

Product Image

C purlin roll forming machine 1
Img 1
C purlin roll forming machine 2
Img 2
C purlin roll forming machine 3
Img 3
