| Model: | H12-NS3-AG120 |
|---|---|
| Brand: | YYH |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Other Electrical & Electronic |
| Label: | LED modules , Led lighting , 3 led light module |
| Price: |
US $0.4
/ pc
|
| Min. Order: | 5000 pc |
| Live Chat: | Last Online:05 Aug, 2015 |
Features
Ø Stylish appearance design with cap type
Ø Take high efficiency SMD Chip as light source application
Ø LED Chip applied by famous brands, Cree, Samsung, Epistar etc
Ø High brightness,large emitting angle ,low thermal resistance
Ø Low light decay and high uniformity of the emitting color
Ø Fabricated with a CAP TYPE Optical Lens
Ø With pure copper wire for a low thermal resistance
Ø Each unit can be used to cut
Ø Safety, energy saving and Eco-friendly
Ø UL/CE and RoHs approved
Typical Applications
Ø Channel letters
Ø Advertising letters
Ø Decorative lighting
Ø Sign and signage and light box illumination
Ø Replaces neon/fluorescent lighting
Product parameters
|
LED chip brand |
Cree / Samsung / Epistar |
|
Chip size |
5054 |
|
Operating voltage |
DC 12V / 24V |
|
Power dissipation |
1.2W |
|
Emitting angle |
160° |
|
Luminous intensity |
60-70lm（typ.） |
|
Dimension |
66*17*8 mm （L x W x H） |
|
LED quantity |
3 pcs |
|
Emitting color |
Green |
|
Waterproofing rate |
IP67 |
|
IP type |
Injection workmanship |
|
Material of main cabinet |
ABS , fireproof and inflame retarding |
|
Material of Lens |
Optical Lens, fireproof and inflame retarding |
|
Color of main Cabinet |
White |
|
Material of connecting cable |
UL18 AWG， 300V/105°C |
|
Color of connecting cable |
Positive: red; negative: white |
|
Max. In series |
Based on Power Voltage Supply |
|
Adhesive type |
3M adhesive Sponge |
|
Operating temperature |
-20~60℃ |
|
Storage temperature |
-30~70℃ |
|
Warranty |
5 years |
