| Model: | redstarwiremesh |
|---|---|
| Brand: | redstarwiremesh |
| Origin: | Made In China |
| Category: | Metallurgy , Mining & Energy / Metallurgy & Mining / Wire Mesh |
| Label: | vibrating screen mes , rotary screen , 12mm Mesh screen |
| Price: |
US $70
/ pc
|
| Min. Order: | 20 pc |
| Live Chat: |  | Last Online:03 Nov, 2023 |
Stone Crusher Vibrating Screen Mesh
not brittle .smooth surface suitable tightness precision surface mesh ,aperture founder
Stone Crusher Vibrating Screen Mesh
Mining screen mesh
| No. | Grade | chemical composition(%) C | Si | Mn | Wire diameter(mm) |
| 1 | 45 | 0.42-0.50 | 0.17-0.37 | 0.50-0.80 | 2.00-6.00 |
| 2 | 50 | 0.47-0.55 | 0.17-0.37 | 0.50-0.80 | |
| 3 | 55 | 0.52-0.60 | 0.17-0.37 | 0.50-0.80 | |
| 4 | 50 | 0.57-0.65 | 0.17-0.37 | 0.50-0.80 | |
| 5 | 65 | 0.62-0.70 | 0.17-0.37 | 0.50-0.80 | |
| 6 | 70 |
0.67-0.75
|
0.17-0.37 | 0.50-0.80 | 2.00-6.00 |
| 7 | 65Mn | 0.62-0.70 | 0.17-0.37 | 0.90-1.20 | 2.00--14.0 |
Quality requirement : no brittle ,smooth surface suitable tightness
precision surface mesh ,aperture founder .
Weaving :double crimp screen
single intermediate crimp screen
double intermediate crimp screen
lock crimp screen
flat top screen
pressure welded screen
Kinds : high tensil screen cloth
high tensile steel ------Abrasion resistance
stainless steel ----------corrosion resistance
Monel. Brass etc----------general application
Package : as the clients' requirments
| Payment Terms: | TT / LC |
|---|---|
