| Model: | MS-D245 |
|---|---|
| Brand: | MASUNG |
| Origin: | Made In China |
| Category: | Computers & AV Digital / Computer Components / Mouse & Keyboard |
| Label: | kiosk thermal printe , kiosk printer , 2 inch USB printer |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:12 May, 2015 |
Model: MS-D245
2 inch thermal kiosk printer
Features:
Brand name printer mechanism
Reliable auto cutter
Compact panel mounted structure
Ultra high speed
Wide input voltage range
Full/partial cutting (by adjustable)
Rear paper auto loading
Specification:
|
mechanism： |
CAPD245 |
||
|
Printing method |
Thermal dot line printing |
||
|
Dots/line |
384 dots/line |
||
|
Dot pitch |
8 dot/mm |
||
|
Paper width |
58 mm |
||
|
Printing width |
48 mm |
||
|
Paper thickness |
54~91 um |
||
|
Printing speed |
150 mm/s |
||
|
Paper loading |
Paper auto loading |
||
|
Sensors |
Head temperature |
Thermistor |
|
|
Paper press shaft |
Mechanical switch |
||
|
Paper end |
Photo interrupter |
||
|
Font size |
ASCII:9*17;12*24; Chinese: 24*24 |
||
|
Power supply |
Logic circuit |
2.6~3.6 V |
|
|
Motor |
4.75 ~9.5 V |
||
|
Reliability |
Circuit: over 1,000,000,000 pulses Cutter: over 7,000,000 cuts Thermal head: over 100 km MCBF: 37,000,000 lines |
||
|
Ambient environment |
Work temperature |
-10 ℃~50℃ |
|
|
Work humidity |
20~85% RH |
||
|
Storage temperature |
-25℃~70℃ |
||
|
Storage temperature |
10~90% RH |
||
|
Dimension (L*W*H) |
117.85*103.5*93 mm |
|
|
|
Weight |
Approx 0.45 kg |
|
|
|
Interface |
RS-232 /USB |
||
|
power supply |
DC 9~24V/2.5A |
||
|
Command set |
ESC/POS |
||
|
Barcode |
supported |
||
|
Firmware location |
2 M NV Flash memory |
||
|
Buffer |
4 KB |
||
|
SRAM |
20 KB |
||
|
Driver |
USB driver |
||
|
System |
Windows/Linux/Android OS |
||
|
Accessories: |
paper near end sensor; |
||
|
Paper roll holder |
|||
|
Paper bezel (paper guide mouth) |
|||
|
Interface connector |
|||
|
Power supply unit |
|||
|
Cable |
|||
Applications:
Information kiosk; gas pump station; public payment terminal; ID automation; lottery device; ticket vendor; parking system; queue management machine and more.
