| Model: | MXFQ+P |
|---|---|
| Brand: | MAOXIN |
| Origin: | Made In China |
| Category: | Industrial Supplies / Packaging Related Machine |
| Label: | Outside Patch , plastic bag , bag making |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:10 Aug, 2015 |
Features
* Suitable for producing HDPE, LDPE and other plastic film barrel paper bags, sanitary towel bags, diaper bags, packaging bags.
* Configure the servo motor and the microcomputer control system, liquid crystal display human-computer interface, easy to operate,
The configuration of TL50 photocell eye tracking printing.
* Main motor equipped imported frequency transducer to control the speed real-time. Making stable feeding, sealing and cutting precise.
* Configuration on the heating device, high precision temperature control instrument automatic temperature control, ensure the
pressure sealing mould heat sealing and firm and beautiful.
* External patch using synchronous motor servo motor control, one-step molding, improve the efficiency of.
* Feeding system configuration of synchronous feeding, photoelectric control, DC speed control, feeding is uniform and flat.
* The control system of the machine with automatic counting, the total number, pre-alarm, suspension and other functions,
automatic control equipment, high degree of automation.
* The configuration of strong electrostatic eliminating device, plastic bag folding is more convenient.
* The machine has the advantages of simple operation, fast speed, high automation, stable product quality, high yield.
|
Model |
MXFQ+P-500 |
|
Max.Bag.size |
500mm |
|
Machine speed |
0.01-0.20mm |
|
Thickness of film |
30~130pcs/min |
|
Power Required |
4.2kw |
|
Machine size |
3500x1000x1420mm |
|
Machine N.W |
950kg |
