| Model: | ZL918 series |
|---|---|
| Brand: | - |
| Origin: | Made In China |
| Category: | Industrial Supplies / Construction Machine |
| Label: | wheel loader , mini loader , loader |
| Price: |
-
|
| Min. Order: | - |
| Live Chat: | Last Online:08 Oct, 2022 |
| ITEM | UNIT | Specification | Specification | Specification |
| Model | ZL918A | ZL918 | ZL918C | |
| Rated load | Kg | 1800 | 1600 | 1200 |
| Rated bucket capacity | m3 | 0.45 | 0.42 | 0.42(Wx1600) |
| Overall dimension (L×W×H) | mm | 5200×1700×2600 | 5200×1700×2750 | 6900×2040×3000 |
| Wheelbase | mm | 2010 | 2190 | |
| Wheel track | mm | 1320 | 1470 | |
| Min. turning radius | mm | 4200 | 5000 | |
| Max. climbing ability | ° | 30 | 30 | 30 |
| Min. ground clearance | mm | 240 | 265 | |
| Max. dumping angle | ° | 45 | 45 | |
| Max. dumping height | mm | 2850 | 2850 | 4220 |
| Min. discharge distance | mm | 800 | 800 | 1430 |
| Type and pressure of tyre | 14/90-16；210KPa | 12.00-16；210KPa | 14/90-16；210KPa | |
| Max. speed | Km/h | 25 | 20 | 20 |
| Overall weight | Kg | 3500 | 3000 | 4200 |
| Engine | UNIT | Specification | ||
| Model | Xichai 4DW91-45 | |||
| Power | KW | 37 | ||
| Rotate speed | r/min | 2300 | ||
| Type of cooling | Water cooling | |||
| Transmission Syestem | Specification | |||
| Transmission (Mechanical ) | 2 forwards, 2 reverses | |||
| Torque converter | One-phase,single-stage,three element | |||
| Brake control | Hydraulic power | |||
| Advantages: | 1. Fully enclosed cab, bright and spacious; new cab damping system to make work more comfortable. 2. Xichai 4DW91-45 diesel engine, reliable, strong power, low fuel consumption, long service life. 3. Hydraulic load-sensing steering system makes turning more flexible and lightweight. 4. Working device with automatic leveling function, greatly reducing the driver's work intensity. 5. Using new dual seal piping, so that the hydraulic system is more reliable and stable. 6. Using a single-stage single three-component fixed-shaft gearbox with torque converter, make full use of engine power, increased torque, the machine has great traction. 7. Gearbox adopts new commutation control valve, making walking more flexible and convenient. 8. Hydraulic brake system, so that the shortest braking distance. |
|---|---|
| Min Order: | 1 set |
| Standard Met: | CE |
