| Model: | DH-SMJ-D |
|---|---|
| Brand: | Asia Star |
| Origin: | Made In China |
| Category: | Industrial Supplies / Packaging Related Machine |
| Label: | wet Tissue , folding machine , Wet Tissue Packing |
| Price: |
US $30500
/ SET
|
| Min. Order: | 1 SET |
| Live Chat: |  | Last Online:22 Dec, 2017 |
1 . DH-SMJ-D automatic wet wipe folding machine
The machine adopts Frequency speed controlling system , which is made up of raw material loading device, tension device, folding device,automatic wetting system(with agitating and circulating function), autoamtic counting and folding alignment device, finished products slitting device etc.
The cover of machine and the parts touching with the products are made of stainless steel,the special folder has various folding ways.
Main Technical Parameter:
|
Suitable material |
Spunlace non-woven, hot rolling non-woven fabrics, Air-laid paper |
|
GSM of raw material |
40-80g/m2 |
|
Capacity speed |
350-600pcs/min |
|
Folding way |
multifunctional ways |
|
Size of product (unfolded) |
200 x 200 (MM)(L x W) |
|
Size of product (folded) |
100 x 70 (MM)(L x W) |
|
Specification of raw material |
200 x 1200 (MM)(L x W) |
|
Machine size |
4500 x 1200 x 1650 (MM) (L x W x H) |
|
Machine weight |
1100KG |
|
Electrical source |
AC220V 50/60Hz |
|
Power: |
3.5KW |
2 . DH-DB500 Full-auto Wet Tissue Packing Machine
The machine is suitable for packing 3-30pcs/pack.
Working procedure:date printing-punching-labeling-packing
Main technical parameters:
|
Capacity speed |
30-80packs/min |
|
Max width of packing of film |
410mm |
|
Packing lengh |
(100-250)mm |
|
Packing width |
(50-120)mm |
|
Packing high |
(3-35)mm |
|
Suitbale film material |
Opp.pe.pvc.pt/pe.opp/cpp.kop/cpp.paper/pe.pet/aluminum/pe etc |
|
Packing form |
Pillowcase |
|
Controlling system |
PLC control system.full servo motor |
|
Electronic supply |
AC220V 50/60Hz |
|
Power |
4KW |
|
Machine size |
5100x850x1650mm(LxWxH) |
|
Machine weight |
1000KG |
| Payment Terms: | TT |
|---|---|
