| Model: | Drawn Arc |
|---|---|
| Brand: | SINOARS |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machine Hardware / Nuts & Bolts |
| Label: | - |
| Price: |
US $0.1
/ pc
|
| Min. Order: | 5000 pc |
| Live Chat: | Last Online:05 Nov, 2018 |
Specifications
Shear connectors for stud welding;
According to standard of ISO 13918;
Material equal to S235J2G3+C450;
OEM available.
|
Product Name |
Shear Connector |
|
Standard |
ISO 13918 |
|
Type |
SD |
|
Material |
Low carbon steel |
|
Surface Treatment |
Plain / Phosphate. |
|
Flux |
Aluminium tip |
|
Specification |
SD13, SD16, SD19, SD22, SD25 |
|
Welding Through Metal Deck |
Available |
|
Ceramic Ferrule Type |
UF / UFT(For welding through metal deck) |
|
Mechanical Properties |
||
|
Yield strength (ReH) |
min. |
350MPa |
|
Tensile strength (Rm) |
min. |
450MPa |
|
Elongation (A5) |
min. |
15% |
|
Reduction of Area |
min. |
50% |
Applications:
Shear Connectors transfer shear stress between metal and concrete in composite structural members in which thestud is welded to the metal component
Quality Control:
We believe consistant qualitly is one of the important reason that we won great reputation from our customers during the past years, each piece of SINOARSTM shear connectors must be passed stricly SINOARSTM quality control system before deliery to you.
Package:
SINOARSTM provide appropriate package for shear connectors, the default package are cartons (lined with plastic bags) & plywood pallets; we can also provide barrels (lined with plastic bags) & plywood pallets if you have long time stock request.
