| Model: | 21007223-01-001 |
|---|---|
| Brand: | Chogori |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Components / Terminal |
| Label: | Connector , mini connector , 7 pin connector |
| Price: |
-
|
| Min. Order: | 100 pc |
| Live Chat: | Last Online:05 Jan, 2016 |
Specifications
Mini 7 pin molding waterproof connector
1. 7 pin water connector
2. IP67 Protection Level
3. CCC, CE, ROSH
Mini 7 pin waterproof connector
|
field Installable waterproof M14 2 pin cable connector |
|||
|
1 |
Model No. |
21007423-02 | |
|
2 |
Material |
Connector Body |
ABS/PBT/PA66 UL94V-0 1/8” |
|
3 |
Contact |
Brass with Gold Plated |
|
|
4 |
Sealing |
Silica Gel |
|
|
5 |
Property |
Current Rating |
2A |
|
6 |
Voltage Rating |
50V |
|
|
7 |
Contact Resistance |
<10mΩ |
|
|
8 |
Insulation Resistance |
1000MΩ at DC 500V |
|
|
9 |
Breakdown Voltage |
1.5KV/1minute |
|
|
10 |
Temperature Rating |
-45°C~+105°C |
|
|
11 |
Durability(Plug/Unplug) |
3000 times |
|
|
12 |
Waterproof Rating |
IP68 |
|
|
13 |
Cable Max. Diameter |
7.2mm |
|
|
14 |
Contact Range |
2, 3, 4, 5, 6, 2+4 ,7, 8, |
|
|
15 |
Certificate |
CCC; CE; ROSH |
|
| Payment Terms: | TT |
|---|---|
