| Model: | 9 ton front axl |
|---|---|
| Brand: | YIWO |
| Origin: | Made In China |
| Category: | Transportation / Vehicles / Commemical Vehicles |
| Label: | 9 ton front axle , front axle , truck axle |
| Price: |
US $500
/ pc
|
| Min. Order: | 10 pc |
| Live Chat: |  | Last Online:15 Mar, 2016 |
| 9 Ton truck front axle | ||
| Main technical parameters | ||
| Specifications | 90B | 95A |
| Payload (KG) | 9000 | 9000 |
| Max.steering angle of front inner wheel | 47° | 42° |
| Self-weight (KG) | 520 | 540 |
| Track (mm) | 2028 | 2050 |
| Leaf spring center distance (mm) | 860-900 | 850-890 |
| Kingpin centre (mm) | 1748 | 1790 |
| Gap of front axle (mm) | 127 | 127 |
| Diameter of hub bolt distributed cicular (mm) | Φ335 | Φ335 |
| Brake specification | Φ420*175 | Φ420*175 |
| Kingpin inclination angle (mm) | 6.75° | 6° |
| camber angle | 0.25° | 1° |
| Toeing-in (mm) | 0-2 | 0-2 |
| The front axle apply to all types of bus, truck, and are optional with ABS, disc brake and air suspension | ||
Main products:
Truck axle(Front axle and rear drive axle,tandem axle,tridem axle)
Trailer axle(Germany type axle and America type axle)
Tractor axle (120 hp tractor axle and 160 tractor axle and more big hp tractor axle)
Axle parts(all kinds of gear)
Contact us
E-mail:Jessica.ma@ywvehicle.com
Skype:Jessicayiwo
| Payment Terms: | T/T |
|---|---|
