Basic Description

Vehicle Model

SLA5250GFLDFL6

Chassis Model

DFL1250A9

GVW (kg)

25000

Loading capacity (kg)

10000

Curb weight (kg)

14870

Max speed (Km/h)

90

Overall dimension

(LxWxH mm)

11200x2500x3950

Tank volume(m3)

26

Chassis Description

Allowable Passengers In Cab

2

Wheel base(mm)

5700+1300

Number of axles

3

Traction system

6x4

Front wheel tread(mm)

1986

Rear wheel tread(mm)

1860/1860

F/R overhang(mm)

1460/3090

F/R axle-load(kg)

7000/18000

Type of fuel

Diesel

Emission standard

EURO III

Tire specification

11.00R20 18PR

Tire quantity

10

Gearbox

9JS119T-B (9 speed transmission)

Transmission Type

Manual

Engine Description

Engine model

Displacement/output

Horse power

Brand

C245

8300/180

245

Dongfeng

Compressor Description

Rated exhaust capacity

(m3/min)

Rated exhaust pressure

(Mpa)

Dimension

(mm)

Rotational Speed

(r/min)

8.0

0.2

998x680x30

1100
