| Model: | YT Series |
|---|---|
| Brand: | Zhuxin |
| Origin: | Made In China |
| Category: | Industrial Supplies / Plate Making & Printing Machine |
| Label: | printing machine , printer , flexo print machine |
| Price: |
US $10000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:06 Aug, 2021 |
Performance and Characteristics:
This machine is suitable for printing such packing materials as polyethylene,polypropylene bag,glass paper and roll paper,etc.And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.And it is a kind of ideal printing equipment for producing paper packing bag for food,supermarket handbag,vest bag and clothes bag, etc.
Main Technical Variables:
|
Model of Machine |
YT-6600 |
YT-6800 |
YT-61000 |
|
Max.Width of Substrate（mm） |
600mm |
800mm |
1000mm |
|
Max.Printing Width（mm） |
560mm |
760mm |
960mm |
|
Range of printing Length（mm） |
191-1100mm |
191-1100mm |
191-1100mm |
|
Max.Diameter of web（mm） |
ф450mm |
ф450mm |
ф450mm |
|
Printing Speed（m/min） |
5-50m/min |
5-50m/min |
5-50m/min |
|
Plate Thickness
|
2.38mm |
2.38mm |
2.38mm |
|
Total Power（kw） |
27.25kw |
27.25kw |
27.25kw |
|
Weight of Machine（kg） |
3500kg |
4200kg |
4500kg |
|
Overall Dimensions （L*W*H） （mm） |
4200×1660×2950mm |
4200×1860×2950mm |
4200×2060×2950mm |
