electric truck ，electric mini truck,electric vehicle(RUNBAO-D)

Model:RUNBAO-D
Brand:RUNDA
Origin:Made In China
Category:Transportation / Vehicles / Special Transportation Equipment
Label:electric truck , electric vehicle , electric car
Price: ¥4200 / pc
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Weifang Runda machinery co.Ltd

Free MemberShan Dong - China
Live Chat:点击这里给我发消息Last Online:19 Nov, 2021

View all products. (20)

Product Description

 Specification 2.2m Carriage 2.6m Carriage 2.2m Container 2.5m Container
Vehicle Parameters 　
L*W*H  (Overall Dimension)            mm 3600ｘ1300ｘ1790 4000ｘ1300ｘ1790 3600ｘ1300ｘ1900 3900ｘ1300ｘ1900
L*W*H (Carriage/Container Dimension)       mm  2200ｘ1300ｘ400 2600ｘ1300ｘ400 2200ｘ1300ｘ1300 2500ｘ1300ｘ1300
Wheelbase                      mm 1860
Tread                               mm 1260
Min. Ground Clearance (Full loaded/ Half loaded)mm   180
Min. Turning Radius          m ≤5
Curb Weight                       kg 660 680 700 720
Tire Specification 145/70R12
Max. Speed                            km/h 45
Max. Gradability                % 20-30
Electric Comsumption of Hundred Kilometer          kwh 10
Transmission Form Stepless speed change
Electric Motor 　
Model Brushless DC Electric Motor/ Communication AC Electric Motor
Rated Voltage                    v 72
Rated KW                        kw 2.5-4
Rated Turning Speed           3850-4500
Braking suspension driving mode 　
Braking System Drum brake
Suspension System Front: Mcpherson independent suspension  Back: Steel Suspension
Driving Model Rear Drive
Battery (lead acid battery) 　
Rated capacity                 Ah 120-150
Rated Voltage                    v 72
Charger 　
Input Voltage 220v(Communication)
Charging Time 8-10 hours
Endurance Mileage 100-150
