| Model: | OA-80 |
|---|---|
| Brand: | ASLi |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Laboratory Instrument |
| Label: | Ozone Aging chmaber , Ozone Aging Tester , aging room |
| Price: |
US $10000
/ set
|
| Min. Order: | 1 set |
| Live Chat: | Last Online:28 May, 2018 |
Ozone Aging Test Chamber
Application: Ozone Aging Test Chamber is used to test the ozone environment, the characteristics of crack-resistant rubber, ozone resistance testing machine, can control and adjust the concentration of ozone environment, to determine the anti-ozone properties of the specimen. The equipment can comply with the standard: JISK6259 ASTM1149 ISO1431 GB/TTB62 GB/T13642
Pls feel free to contact us for detail specifications.
Rachel@aslitesting.com
(Ms.Rachel Lee)
Tel.:0086-769-23164266
Cell:0086-13602387384
Skype:asli168
Technical parameters:
|
Model |
OA-80 |
OA-408 |
OA-800 |
|
Internal Dimensions WxHxD (mm) |
400x500x400 |
600x850x800 |
1000x1000x800 |
|
Internal Dimensions WxHxD (mm) |
950x1650x950 |
1200x1950x1350 |
1600x2000x1450 |
|
Temperature Range |
RT+10℃~+65℃ |
||
|
Control Accuracy of Temperature |
±0.5℃ |
||
|
Distribution Uniformity of Temperature |
±2.0℃ |
||
|
Analytic Accuracy of temperature |
0.1℃ |
||
|
Ozone Concentration( pphm) |
1~1000， adjustable |
||
|
Deviation of Ozone Concentration |
≤10% |
||
|
Ozone Generator |
Silent discharge tube type |
||
|
Internal and External Material |
Material of the inner box is SUS 304# stainless steel，of the outer box is stainless steel or SEE cold-rolled steel with paint coated. |
||
|
Insulation Material |
Polyurethane rigid foam / superfine glass fiber cotton |
||
|
Security |
Leakage, short circuit, over-current protection |
||
|
Power |
AC 220V |
||
