IP67 COB LED Sided Inground Light

Model:	-
Brand:	Comlite
Origin:	Made In China
Category:	Consumer Electronics & Lighting / Lighting / LED Lighting
Label:	Sided Inground Light , ip68 cob led lights , 5w 24VDC cob lights
Price:	-
Min. Order:	-

Inquire Now Add to Basket

Member Information

Comlite Led Limited

Biz MemberGuang Dong - China

Live Chat:

Last Online:05 Oct, 2023

Product Description

features:

1.Rhombic lens create even light distribution without glare

2.The light scene effect be enhanced with the fitting installed along the wall of the building or under the shrub.

specifications:

Housing:	12# die-casting grey powder coated aluminum. T=60-80um Adhesion of ISO class 1/ASTM class 4B
Front cover:	316# stainless steel
Loading capacity:	>2000kg
Cable gland:	IP-67 copper and nickel coated
Gasket:	Molding shaped silicone seal
Driver	Constant current output
Operating temperature:	-20-40℃
Power cable:	H05RN-F 3X0.75m㎡ L=0.5m (high voltage)
Mounting sleeve:	12 Die-casting grey powder coated aluminum . T=60-80µm.

Technique Parameters:
Item No.

Light Source

Lens Beam Angle(°)

Input (V)

Typical Current
(mA)

Typical Consumption
(W)

1E2AES0125	1X5W COB LED	30	24VDC	210	5
			120VAC	86	6.3
			240VAC	54	6.8
2E2AES0125	1X5W COB LED	30	24VDC	210	5
			120VAC	86	6.3
			240VAC	54	6.8
4E2AES0125	1X5W COB LED	30	24VDC	210	5
			120VAC	86	6.3
			240VAC	54	6.8

Payment Terms:	TT/Paypal

Product Image

Img 1

Img 2

Img 3
