Set a PCT.CC-1 consists of piercing clamp(PCT) and the standard module with pin lock branch (FCC1).
Connectors are used for temporary power take off or short circuiting. PCT.CC-1 ability to install the assembly to the line under tension without removing the insulation from the wire.

- Connector with an insulated structure getting a high mechanical and climatic resistance.
- Tap side equipped with a security stud fitted with a bayonet locking.
- Water tightness system to restore insulation , flashover resistance 6kv deeped in water.
- Easy to use and install: insulating piercing (PCT), shear head, screw never on potential, stud protected against direct contact.

Type         Specification               Piercing Connector
PCT.CC-1   IPC range: 6-150mm2             PCT13 150/150
           Branch Pin lock : 500V,63A ,
                             1.5-16mm2
FCC1 500V, 63A , 1.5-16mm2              PCT series: PCT.CC-1
                                        TTD series: TTD.CC-1
                                        JBC series: JBC.CC-1
