| Model: | PFSI |
|---|---|
| Brand: | Flyin |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Optical Fiber, Cable & Wire / Optical Fiber |
| Label: | təcridxanalarının , Izolatory , isolatoren |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:27 Dec, 2017 |
Feature
l High Isolation
l Compact Size
Applications
l Light Source for Optical Amplifiers
l Tunable laser Module
l Semiconductro Laser Module
Performance Specifications
|
Parameter |
Specification |
|
Operating Wavelength (nm) |
1310 or 1550 or CWDM Wavelength |
|
Isolation ( at 23 ℃) (dB) |
≧30 |
|
Insertion Loss (at 23 ℃) (dB) |
≦0.30 |
|
Outer Diameter (mm) |
2.5 |
|
Capillary End Angle (℃) |
6～8 |
|
Fiber Type |
F0.9mm SMF-28 |
|
Connector Type |
FC; SC; ST/LC |
|
Operating Temperature |
-20 to +85 |
|
Storage Temperature |
-40 to +85 |
* All values referenced without connector
Ordering information
|
PFSI |
X |
XX |
X |
XX |
|
|
Housing Length |
Wavelength |
Fiber Length |
In/Out Connector |
|
|
1=14.5mn 2=Customized |
13=1310nm 15=1550nm X=Customized |
1=1.0m 2=1.5m 3=2.0m X=Customized |
0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=ST 6=LC |
| Payment Terms: | 100% TT in advance |
|---|---|
