| Model: | - |
|---|---|
| Brand: | NP |
| Origin: | Made In China |
| Category: | Metallurgy , Mining & Energy / New Energy / Solar Energy |
| Label: | solar water heater , manifold collector , solar collector |
| Price: |
US $200
/ pc
|
| Min. Order: | 100 pc |
| Live Chat: | Last Online:01 Jul, 2013 |
|
Storage tank volume
|
|
Outer casing: aluminium alloy thickness :0.5mm
|
|
Inter tank: SUS304 2b stainless steel
|
|
Insulation layer: polyurethane foam /rock wool for optional
|
|
Inlet and outlet:SUS304 2b
|
|
Heat preservation:72 hours
|
|
Welding: Arg welding
|
|
Vacuum tube
|
|
Number of tube:20L ,24L,26L,28L,32L for optional
|
|
Tube length:47*1500/58*1800/47*1800 for optional
|
|
Heat absorption rate :91%
|
|
Thermal damage rate:ULT =0.82W/(m2•℃)
|
|
Coating of vacuum tube: AL/N/AL
|
|
Heat pipe: anti-freeszing>-35
|
|
Hail resistance:25mm
|
|
Working pressure: 6bar
|
|
Max test pressure:12bar
|
|
Max working temperature: 280C
|
|
Tube holder: UV stabilized nylon
|
|
Support
|
|
Aluminum alloy
|
